Custom Glass Wool Roll

The Custom Glass Wool Roll is a versatile, high-performance insulation material designed for thermal and acoustic efficiency in modern buildings. As a type of glass wool roll, it is manufactured from inorganic glass fibers, resulting in a lightweight, resilient, and non-combustible product. It provides exceptional thermal performance (with low thermal conductivity), excellent sound absorption, and will not release toxic gases when exposed to fire, making it an environmentally responsible choice. Sunjoy offers this high-quality product in both standard and customized forms, including various facings like aluminum foil, to meet the specific demands of your project.

Aluminum foil faced glass wool insulation blankets will also be available.

Aluminum foil laminated glass wool blanket meets the market's high standard demand for green and environmentally friendly building materials, avoiding the harm of harmful substances such as formaldehyde and phenol to the human body and the environment. Moreover, aluminum foil laminated glass wool blanket can maintain good thermal insulation performance regardless of high or low temperature environment.





Custom Glass Wool Roll Service

Density & Thickness: We can adjust the nominal density (from 10 to 48 kg/m³) and thickness to meet specific thermal or acoustic targets.

Dimensions: Length and width can be tailored to your installation needs, reducing on-site waste.

Facing Materials: A wide range of facings is available, including aluminum foil, kraft paper, black tissue, PVC, vinyl, or we can work with you to develop a custom facing.

Packaging: We can customize the packaging type (vacuum, compression) and labeling to suit your logistics and handling preferences.



How to Choose The Glass Wool Roll

Determine Thermal Requirements: Calculate the needed R-value / thermal resistance for your climate and building code. This will dictate the required thickness and density.

Identify the Application:

• For walls and floors, a standard density roll (e.g., 14-18 kg/m³) is commonly used.
• For HVAC and ductwork, a foil-faced roll is essential for vapor control and condensation prevention.
• For metal buildings, consider options with reinforced facings for durability.

Consider Acoustic Needs: If sound control is a priority, all glass wool rolls provide excellent acoustic absorption, but specific densities can be optimized.

Check for Compliance: Ensure the chosen product meets local fire safety and environmental standards (e.g., non-combustibility, no toxic gas emission).



The Glass Wool Roll Comparison with Other Types

Feature	Custom Glass Wool Roll	Rock Wool Roll / Board	Rigid Foam Board (e.g., EPS/XPS)
Primary Material	Molten glass fibers	Molten stone/slag fibers	Polystyrene plastic
Structure	Flexible, fibrous roll	Fibrous (roll or semi-rigid board)	Rigid, closed-cell board
Thermal Performance	Excellent (low conductivity)	Excellent (slightly higher than glass wool)	Excellent (very low conductivity)
Fire Resistance	Non-combustible (Class A)	Non-combustible (Class A)	Combustible (may require fire barrier)
Acoustic Performance	Excellent (fibrous structure absorbs sound)	Excellent (denser, good for sound blocking)	Poor (can reflect sound)
Vapor Permeability	High (allows walls to breathe, unless foil-faced)	High	Low (acts as vapor barrier)
Ease of Installation	Easy to cut and fit in cavities	Can be slightly harder to cut; good friction fit	Requires precise cutting and sealing of joints

Custom Glass Wool Roll Packing

Common PE Bag: Standard packaging in polyethylene bags. This method is simple but occupies more volume.

Vacuum PE Bag (Recommended): The roll is compressed and vacuum-sealed in a PE bag. This significantly reduces volume, optimizes container loading, and lowers shipping costs.

Compressed PE Bag: A cost-effective compression method that reduces volume more than common bags, though the final packed size is larger than vacuum packaging.



Product Specification

	Length(mm)	Width (mm)	Thickness(mm)
GLASS WOOL ROLL 10	7,000-30,000	600/1200	40-200
GLASS WOOL ROLL 12	7,000-30,000	600/1200	35-200
GLASS WOOL ROLL 14	7,000-30,000	600/1200	30-150
GLASS WOOL ROLL 16	7,000-30,000	600/1200	25-150
GLASS WOOL ROLL 18	7,000-30,000	600/1200	25-150
GLASS WOOL ROLL 24	7,000-30,000	600/1200	25-150
GLASS WOOL ROLL 32	7,000-30,000	600/1200	25-150
GLASS WOOL ROLL 40	7,000-30,000	600/1200	25-150
GLASS WOOL ROLL 48	7,000-30,000	600/1200	25-150
Facing	Aluminum foil, kraft-paper, black tissue, PVC, vinyl, etc. or customized
Remark	other specification, please contact our sales

R-value

	50mm		75mm		100mm		150mm
Type	Metric	English	Metric	English	Metric	English	Metric	English
	m3°C/W	hr.°F/btu	m3°C/W	hr.°F/btu	m3°C/W	hr.°F/btu	m3°C/W	hr.°F/btu
GLASS WOOL ROLL10	1.01	5.9	0.98	8.9	2.25	12.5	3.32
GLASS WOOL ROLL12	1.16	6.6	1.74	9.9	2.33	13.2	3.49	18.1
GLASS WOOL ROLL14	1.25	7.1	1.88	10.7	2.55	14.2	3.75	19.8
GLASS WOOL ROLL16	1.28	7.3	1.92	10.9	2.66	14.6	3.85	21.3
GLASS WOOL ROLL18	1.35	7.7	2.03	11.5	2.7	15.4	4.05	21.8
GLASS WOOL ROLL24	1.39	7.9	2.08	11.5	2.78	15.8	4.17	23.7
GLASS WOOL ROLL32	1.47	8.4	2.21	12.5	2.94	16.7	4.41	25.1
GLASS WOOL ROLL40	1.52	8.6	2.27	12.9	3.03	17.2	4.55	25.8
GLASS WOOL ROLL48	1.56	8.9	2.34	13.3	3.13	17.8	4.69	26.8

Technical Data

ltem	Test Properties	Standard	Test Result
1	Density and Dimension	ASTM C 167	pass
2	Non-Fibrous (Shot) Content %	ASTM C 1335	15
3	Apparent Thermal Conductivity	ASTM C518	-4°C 0.030 W/(m·K) 24°C 0.034 W/(m·K) 38°C 0.036 W/(m·K) 93°C 0.042 W/(m·K) 149°C 0.050W/(m·K) 204°C 0.058W/(m·K) 260°C 0.070W/(m·K) 316°C 0.090W/(m·k) 371°C 0.102W/(m·K)
4	Maximum Use temperature and Exothermic Rise Temperature	ASTM C411 /ASTM C447	400°C
5	Odor Emission	ASTM C 1304	No considered the odor  wasobjectionable and strong.
6	Corrosion to Steel	ASTM C 665	36
7	Rigidity and Semi-rigidity	ASTM C 1101 /C 1101M	no visiable rupture in surface
8	Water Vapor Sorption	ASTM C 1104/ASTM C1104M	0.02
9	Surface Burning Characteristic Test	ASTM E84	0
10	Non-combustibility	ASTM E136-16a	non-combustibility

· Category A fireproof

·No change in dimension in case of exposure to heat and humidity

·Not fall off in time, decay, get moldy, corrosion affected or oxidize.

·Not battered by bugs and microorganisms.

·Not torn during application or reduces by wastage due to the specifications of the glasswool.

·Easily adapts to any type of wood and metal roof.

·Easily be taken to the roof and applied by cutting.

·Durable against acidity.

·Decreases the fuel consumption of the buildings by a significant amount.

·Acts as sound isolation as well as thermal isolation with its vibration conserving feature.



Building Envelope: Ideal for thermal and acoustic insulation in wood or steel stud walls, floor joists, and cathedral ceilings.

Roof Insulation: Easily adapts to various wood and metal roof profiles for effective thermal barriers in attics and vented roofs.

HVAC Systems: Used for wrapping air conditioning ducts, pipes, and equipment (often with a foil facing) to prevent energy loss and condensation.

Metal Buildings: Provides complete insulation solutions for metal structures, offering thermal efficiency and interior finish options.

Industrial Equipment: Suitable for thermal and acoustic insulation of solar energy systems, tanks, and industrial process equipment.



Custom Glass Wool Roll Supplier Capability | Sunjoy

Scale & Capacity: We operate 15 advanced production lines across multiple facilities, ensuring consistent supply and timely delivery.

Expertise: Our team includes over 200 R&D and technical personnel dedicated to product development and quality optimization.

Certified Quality: Our products and processes are validated by international certifications, including ISO9001, CE (for glass wool), RoHS, and ASTM standards.

Proven Track Record: We are a trusted supplier to major state-owned enterprises and have successfully delivered projects across Southeast Asia, South America, and the Middle East.

Comprehensive Support: From free samples and pre-sales technical advice to after-sales support, our team provides professional, one-on-one assistance throughout your project.

Glass wool insulation blanket has non-combustible, heat-insulating and sound-insulating properties. It will not release toxic gases when exposed to fire and is one of the most environmentally friendly choices in the field of overall building insulation.
